ANSI B16.5 Blind Flange
Blind flange, additionally recognized as blind flange, is formally known as flange cover. It is a flange besides a gap in the middle, used to seal pipeline plugs. There are many kinds of sealing surfaces, which include flat, convex, concave convex, tenon groove, and ring connection surfaces.
American standard flange is a component that connects pipes to each other and is connected to the pipe end. The American standard flange has eyelets and bolts to tightly connect the two flanges. The flanges are sealed with gaskets. American standard flanges can be cast or threaded or welded.
In industrial pipelines, American standard flange connections are widely used. In the home, the diameter of the pipeline is small and it is low pressure, so flange connections cannot be seen. If in a boiler room or production site, flange connected pipes and equipment can be seen everywhere
| 1. Standard: | ANSI B16.5 | |
| 2. Type: | Plate flange,Slip on,Blind，Lap Joint flange | |
| 3. Pressure Class: | Class 150,Class 300,Class 400,Class 600 | |
| 4. Dimension: | 1/2''-24'' | |
| 5. Surface Treament: | Anti-rust oil; Yellow paint; Black paint;Hot dip Galavnised; Zinc. | |
| 6. Raw Material: | A105;A105N | |
| 7. Packing： | Wooden Case, Pallet. | |
| 8. Payment: | L/C, T/T | |
| 9. Delivery time: | 30 ~60 days after confirm the order | |
| 1. Standard: | ANSI B16.5 | |
| 2. Type: | Plate flange,Slip on,Blind，Lap Joint flange | |
| 3. Pressure Class: | Class 150,Class 300,Class 400,Class 600 | |
| 4. Dimension: | 1/2''-24'' | |
| 5. Surface Treament: | Anti-rust oil; Yellow paint; Black paint;Hot dip Galavnised; Zinc. | |
| 6. Raw Material: | A105;A105N | |
| 7. Packing： | Wooden Case, Pallet. | |
| 8. Payment: | L/C, T/T | |
| 9. Delivery time: | 30 ~60 days after confirm the order | |
